2020 hot sale 4-6t/h corn maize grinder hammer mill for chicken poultry feed making line

2020-11-25 Back to List

2020 hot sale ce approval 4-6t/h corn maize grinder hammer mill,is a high efficient feed hammer mill for regular normal- and coarse-grinding demands, particularly in feed pre-/post-grinding,suitable for broiler chicken poultry feed making line.

1.Parameter of 4-6t/h poultry fodder grinder crop crusher machine for poultry feed pellet making plant

Model:SFSP56*40b

Production Capacity(t/h):4-6

Power:37KW

Speed:2980r/min

2.Advantages of 4-6t/h grain corn maize grinding hammer mill for chicken poultry feed mill plant

(1)Host machine uses direct drive with automatic and uniform feeding mechanism, feeding amount can achieve automatic control.

(2)The main component rotor, can realize bi-directional rotation through the high precision dynamic balancing test.

(3)The hammer after special heat treatment has good quality, high grinding rate. The operation door is equipped with self-locking device, flexible and convenient, safe and reliable.

(4)Used for the grinding of raw materials like organic garbage, drug residue, winery, sugar, etc.

(5)Used for the grinding of biological fermentation wet materials, like livestock and poultry excrement.

(6)The water allowable value of organic fertilizer materials reaches 25-55%, and particle size can reach the requirement of pelleting.

(7)Solve the problem of materials with high moisture, the grinding of organic materials treated by fermentation has better effect.

(8)High-speed rotating blade makes good grinding fineness, high efficiency and low energy consumption.

(9)Use high alloy wear-resistant hammer, more wear-resistant than ordinary hammer, and the service life of the hammer is increased.

3. 12 Things that should be paid attention to in the use of 4-6t/h corn grinding hammer mill machine for poultry chicken feed

(1) The 4-6 ton per hour animal poultry chicken food hammer mill machine must be fixedly installed, and the axis of the grinder pulley and the power machine pulley should be parallel, and the grooves of the two drive pulleys must be in the same straight line. Otherwise, not only will the speed of the machine be damaged, but also the belt will be easily dropped.

(2) If the pulley needs to be modified, it must be calculated to meet the needs of the spindle speed of the crusher. Do not increase the spindle speed at will. When the speed exceeds 15% of the rated speed, the 4-6t/h electric poultry chicken feed corn hammer mill will vibrate violently.

(3) The raw materials must be carefully cleaned in advance, and sieved or selected when necessary to prevent iron and stones from entering the 4-6t/h maize grinding hammer mill.

(4) Before each use, open the cover of the crusher and check whether there is any damage to the various parts in the machine, especially whether the split pin on the rotor is intact and whether the connection is loose. After confirming that it is intact, close the cover firmly and screw in the handwheel on the door. Drag the belt by hand to check whether the moving part is flexible, whether there are abnormal noises and jams.

(5) After the 4-6t/h grain corn hammer mill on poultry chicken feed production line is started, it needs to run idling for 2-3 minutes, and then gradually add materials after it runs normally.

(6) The operator should tighten the cuffs, wear a mask, and work with gloves is strictly prohibited; when feeding the material, stand on the side of the crusher to prevent rebound debris from hurting the face; when crushing long-stalk crops, the hands should not be pinched. The defensive hand was pulled back by the crop and injured.

(7) Feeding should follow the principle of "uniform feeding, small amount and quick feeding", that is, from less to more, until the load is normal, and keep it continuous and uniform to prevent "traffic jam".

(8) If the material inlet is blocked, do not use wooden sticks or iron rods to poke them to prevent the sticks from being brought into the machine or ejected and hurting people. It is also not allowed to reach into the material inlet to shift materials. You can use a harder stem Push the raw materials into the crushing chamber.

(9) Pay close attention to the operating conditions. If vibration, abnormal noise, blockage or spraying materials are found, stop the machine immediately and check and eliminate it. It is strictly forbidden to use wooden sticks or hands to forcibly feed or pull materials without stopping the chicken feed hammer mill grinder with 4-6 ton capacity to avoid injury to the arm or break the poultry animal feed crusher .

(10) It is strictly forbidden to open the door of the poultry chicken feed grinder when the grinder is running; protective devices should be installed for the belt drive; long-term overload operation is forbidden; various tools shall not be placed on the grinder and materials at will, so as not to fall into the machine; smoking is prohibited in the workplace , Pay attention to waterproof and moisture-proof.

(11) The self-made powder bag should be made of fabric with good air permeability, and the length should not be less than 1.5 meters. If the powder bag is not ventilated or too short, it may cause back spray at the inlet.

(12) Feeding should be stopped before shutting down, and the 4-6 tonne per hour poultry fodder grinder should be shut down after the materials in the standby are drained. After the operation, dust and lubrication should be timely.

4.4-6 Ton per hour poultry chicken feed grinding machine price

China factory manufacturing price of 4-6 ton per hour corn grinding hammer mill machine for chicken feed is usually between 5000USD-7000USD.

5.Where to get machinery for grinding poultry feeds?

Looking for poultry chicken feed processing line machinery manufacturer.RICHI is one large animal poultry chicken feed mill plant engineering supplier from China devoting in feed processing equipment, integrating the design, manufacturing, installation, mainly produce all sorts of feed pellet machines, crushing machine, mixing machine, conveying machine, cooling machine,etc and the complete animal feed pellet production line machinery. About more feed processing machines details, please Email: enquiry@cn-pellet.com, Whatsapp/Cel: +86 185 7410 3366.
