Frequency conversion feeding system, steam tempering system, double pressure roller pelletizing system, Siemens electronic control system, plus alloy steel forging body, these become the core of animal feed pellet production.
Brand
RICHI
Capacity
20 Ton Per Hour
Application
Animal
Finished
Pellets
| Model | SZLH250 | SZLH320 | SZLH350 | SZLH420 | SZLH508 | SZLH558 | SZLH678 | SZLH768 |
|---|---|---|---|---|---|---|---|---|
| Main Motor Power(Kw) | 22 | 37 | 55 | 110 | 160 | 185 | 250 | 315 |
| Feeder Power(kw) | 1.1 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 2.2 |
| Conditioner Power(kw) | 1.5 | 4 | 4 | 7.5 | 7.5 | 11 | 11 | 11 |
| Ring Die Inner Diameter (mm) | 250 | 320 | 350 | 420 | 508 | 558 | 673 | 762 |
| Finished Pellets Diameter (mm) | 2~12 | 2~12 | 2~12 | 2~12 | 2~12 | 2~12 | 2~12 | 2~12 |
| Production Output (TPH) | 1.0-1.5 | 3-4 | 5-6 | 10-12 | 15-16 | 20-22 | 30-33 | 38-40 |
Technological innovation is essentially all about customer service. To make you feel the convenience of RICHI's products, technologies and solutions in the process of animal feed production.
Feeding and conditioning systems
The optimized conditioning system with inverter feeding system improves the safety, nutritional value and maturation of the raw material to a great extent. This improves the overall quality of the feed from the source and ensures healthy feeding.
Drive system
High-end Siemens industrial grade drive motor drives the drive shaft of RICHI animal feed pellet mill, which is more stable and durable than traditional belt drive. In the long run, this not only improves efficiency but also saves maintenance costs.
Structure and material
The body of the machine is made of high quality and high specification alloy steel, which is sturdy and durable, reduces resonance and runs stably. The parts that come into contact with the raw material are made of high grade stainless steel, which does not affect the raw material in any way and greatly improves corrosion resistance.
Control and Safety
Each feed pellet mill is equipped with an independent electric control system and safety stop function. It can not only avoid losses caused by perceived errors, but also effectively protect the pellet mill and subsequent production equipment.
Discover our streamlined buying process that makes it simple and efficient for you to get a complete animal feed pellet mill plant. Every step of the way is customized for your convenience, from the initial schematic design and precise manufacturing process to secure payment options and on-site installation and commissioning. At the same time, our dedicated spare parts service ensures ongoing support and optimal machine performance, giving you peace of mind for years to come.
Solution Formulation
Equipment Manufacture
Secure Payment
Spare Parts Service
Essential for preparing and conditioning materials to ensure uniform quality before pelletizing.
The core process where prepared materials are compressed into dense, high-quality feed pellets.
Involves cooling, screening, and packaging to maintain pellet integrity and ready them for use or sale.
Supports the production line by enhancing material flow, reducing downtime, and maintaining operational efficiency.
Includes essential components like ring dies and rollers, crucial for consistent pellet production and machine performance.
HENAN RICHI MACHINERY CO.,LTD
Henan Richi Machinery Co., Ltd was founded in 1995. After nearly thirty years of development and expansion, RICHI Machinery has grown into a modern enterprise covering an area of 60,000 square meters and integrating independent research and development, production and sales.
The products involve feed pellet machinery and engineering, biomass pellet machinery and engineering, organic fertilizer machinery and engineering, conveying equipment and engineering, steel structure engineering, silo, automation control technology and engineering, etc., and each product series has passed ISO 9001 international quality management system certification and CE certification!
Get Quote
This state-of-the-art equipment supports a wide range of feed formulations for poultry and livestock, improving feed quality and reducing production costs. And its scalable design accommodates future expansion.
Learn More
The system is fully automated and requires minimal labor. Customized pellet production solutions can be switched at the touch of a button in the control room for pelletizing a wide range of raw materials.
Learn More
Hardwood residues are processed into durable, high-energy biomass pellets. Designed for industrial production, the system utilizes advanced drying and pelletizing technologies to ensure efficiency and quality.
Learn More
This project is capable of producing fish and shrimp feeds, equipped with precise extrusion technology for superior feed quality. The customer emphasizes its reliability and ease of operation as the main advantages.
Learn More
What kind of animal feed plant do you want to establish?
How many tons per hour about this plant you want to build?
Where is this animal feed plant going to be built?
When do you plan to start the operation?
Absolutely—it’s a workhorse built for large-scale feed production. If you’re producing feed for multiple farms, regional distribution, or export, this model gives you up to 160 tons of pellets per day. That kind of capacity lets you meet big contracts or feed thousands of animals daily without stressing your equipment. One of our clients in Brazil runs this line for poultry and cattle feed supply—and they told us, “This machine paid for itself faster than expected.” If you’re thinking big, the 20TPH feed pellet machine is the backbone you need.
Yes, and that’s where it shines. This animal feed pellet mill can process broiler feed, layer mash, pig grower, dairy pellets, beef cattle feed, and even grass- or hay-based ruminant feeds. It’s also perfect for alfalfa, straw meal, or corn stalk-based feeds, especially when equipped with the right die and feeder setup. In Vietnam, one customer uses the same system for both poultry and goat feed—just switching formulas and die sizes. This machine is built for versatility, so you don’t have to limit your product range.
You’ll want at least 600–1,000 square meters for a full line, depending on your layout. The complete line usually includes:
One client in Egypt set up the whole plant inside a former cotton factory using a modular layout. We provide custom factory layout designs and help you maximize your space whether you're building new or retrofitting an old structure.
Good question. The 20TPH pellet mill for feed is built for high-efficiency production—meaning you’ll get lower operating costs per ton, more consistent pellet quality, and better ROI on bulk orders. If you’re just testing the waters, sure, a smaller model might work. But if you already have market demand or you’re supplying multiple livestock operations, going straight to 20TPH avoids the hassle of upgrading later. Many of our clients say they outgrew their small pelletizer within a year. If you want long-term stability, this model gives you room to scale.
Yes—and we actually recommend this model if you’re planning to make hay or alfalfa pellets. It’s a high-power machine, and when paired with a forced feeder or customized conditioner, it works perfectly as a grass pellet making machine or alfalfa pellet making machine. In Argentina, one customer produces mixed pellets with 70% chopped grass and 30% grain—and it runs smoothly. With a good drying and grinding system, you can turn bulky forage into high-value, easy-to-store pellets.
It can handle a wide range of materials:
Whether you're in Nigeria using maize and palm kernel cake or in Indonesia with rice bran and copra meal—this machine adapts to local ingredients with ease. The key is making sure materials are dry and finely ground. We help you fine-tune the formula to match your animals and local supply chain.
The feed pellet machine price for a 20TPH system varies depending on configuration. You can purchase the pelletizer alone, or as part of a complete turnkey feed line. The full system can include grinding, mixing, cooling, screening, bagging, electrical panels, silos, and dust collection. We provide:
The machine may cost more upfront, but it delivers decade-long returns. Many clients say the efficiency and reliability make it worth every cent.
The main motor is usually 250–280 kW, and the full line can consume 350–400 kW/hour depending on the setup. It runs on three-phase industrial power, typically 380V or 415V. If you’re in a region with unreliable electricity, we can help you calculate the generator size—or even assist with hybrid solutions (diesel + solar). We’ve worked with clients in interior Tanzania and rural Colombia using backup generators successfully. Power planning is part of our service—we won’t leave you guessing.
Not necessarily. You’ll need a team of 3–5 trained operators, depending on the level of automation. We provide:
In Ghana, one client trained local farm workers with zero background in feed mills. Within 3 days, they were operating the whole line efficiently. The automation and control system are intuitive—you don’t need a room full of engineers, just reliable workers and good routines.
We offer full-circle support—from first inquiry to long-term operation. Here’s what’s included:
We’ve supported factories in Ethiopia, Thailand, Brazil, and even remote parts of Ukraine. Whether you're in a big city or off-grid, we’re committed to keeping your plant running at full speed.
