Optimized feed inlet with anti-arching configuration, supplemented by Siemens frequency conversion feeding motor, so that any husk & shell material can be silky smooth into the pelletizing chamber, improve production efficiency and at the same time reduce the failure rate of the equipment.
Brand
RICHI
Raw Material
Rice Husk
Finished
Pellets
| Model | CZLH320 | CZLH350 | CZLH420 | CZLH520 | CZLH678 | CZLH768 |
|---|---|---|---|---|---|---|
| Main Motor Power(Kw) | 22 | 37 | 90 | 132 | 185 | 250 |
| Arch Breaker Feeder Power(Kw) | 2.2 | 2.2 | 3 | 3 | 3 | 4 |
| Forced Feeder Power(Kw) | 0.75 | 0.75 | 1.5 | 1.5 | 1.5 | 1.5 |
| Ring Die Inner Diameter (mm) | 320 | 350 | 420 | 520 | 673 | 762 |
| Finished Pellets Diameter (mm) | 4~12 | 4~12 | 4~12 | 4~12 | 4~12 | 4~12 |
| Production Output (TPH) | 0.5-0.6 | 1.0-1.2 | 1.8-2.0 | 2.8-3.0 | 4.0-5.0 | 6.0-8.0 |
Technological innovation is essentially all about customer service. To make you feel the convenience of RICHI's products, technologies and solutions in the process of husk pellet production.
Feeding systems
The frequency conversion feeding system with anti-arching improves the continuity and consistency of the raw material conveyed to a large extent. At the same time there is still a forced feeder escorting the feeder before pelletizing. This improves the yield and quality of the husk pellet production from the source.
Drive system
High-end Siemens industrial grade drive motor drives the drive shaft of RICHI husk pellet mill, which is more stable and durable than traditional belt drive. In the long run, this not only improves efficiency but also saves maintenance costs.
Structure and material
The body of the machine is made of high quality and high specification alloy steel, which is sturdy and durable, reduces resonance and runs stably. The parts that come into contact with the raw material are made of high grade stainless steel, which does not affect the raw material in any way and greatly improves corrosion resistance.
Control and Safety
Each RICHI pellet machine is equipped with an independent electric control system and safety stop function. It can not only avoid losses caused by perceived errors, but also effectively protect the pellet mill and subsequent production equipment.
Discover our streamlined buying process that makes it simple and efficient for you to get a complete husk pellet production plant. Every step of the way is customized for your convenience, from the initial schematic design and precise manufacturing process to secure payment options and on-site installation and commissioning. At the same time, our dedicated spare parts service ensures ongoing support and optimal machine performance, giving you peace of mind for years to come.
Solution Formulation
Equipment Manufacture
Secure Payment
Spare Parts Service
Essential for preparing and conditioning materials to ensure uniform quality before husk pelletizing.
The core process where prepared grass materials are compressed into dense, high-quality husk pellets.
Involves cooling, screening, and packaging to maintain pellet integrity and ready them for use or sale.
Supports the husk pellet production line by enhancing material flow, reducing downtime, and maintaining operational efficiency.
Includes essential components like ring dies and rollers, crucial for consistent husk pellet production and machine performance.
HENAN RICHI MACHINERY CO.,LTD
Henan Richi Machinery Co., Ltd was founded in 1995. After nearly thirty years of development and expansion, RICHI Machinery has grown into a modern enterprise covering an area of 60,000 square meters and integrating independent research and development, production and sales.
The products involve feed pellet machinery and engineering, biomass pellet machinery and engineering, organic fertilizer machinery and engineering, conveying equipment and engineering, steel structure engineering, silo, automation control technology and engineering, etc., and each product series has passed ISO 9001 international quality management system certification and CE certification!
Get Quote
This state-of-the-art equipment supports a wide range of feed formulations for poultry and livestock, improving feed quality and reducing production costs. And its scalable design accommodates future expansion.
Learn More
The system is fully automated, enabling seamless operation with minimal labor and supporting sustainable agricultural practices through the use of alfalfa and other forages.
Learn More
Hardwood residues are processed into durable, high-energy biomass pellets. Designed for industrial production, the system utilizes advanced drying and pelletizing technologies to ensure efficiency and quality.
Learn More
This project is capable of producing fish and shrimp feeds, equipped with precise extrusion technology for superior feed quality. The customer emphasizes its reliability and ease of operation as the main advantages.
Learn More
What raw materials do you intend to use for pellet production?
How many tons per hour about this plant you want to build?
Where will your pellet mill plant be built?
When do you plan to start this project?
Various types of husks and shells can be processed into pellets, including:
The optimal moisture content for husk pellet production is typically around 10-15%. Maintaining this moisture range is crucial, as it provides enough flexibility for effective compression during pelletizing while avoiding excessive dryness, which can lead to material breakdown. If the moisture is too high, the pellets may be loose or crumble easily; too low, and the material may not bind properly. This balanced moisture level ensures high-quality, dense, and durable husk pellets.
The husk pellet machine typically produces pellets with sizes ranging from 6 to 12 mm in diameter, depending on the die specifications and settings used. This size range makes the pellets suitable for use as biomass fuel or animal bedding, providing versatility for different applications.
The power consumption of a husk pellet machine varies depending on its model and production capacity, but typically ranges from 45 kW to over 100 kW for large-scale production units. Smaller models might use less power, around 15-30 kW, which is suitable for small to medium production needs. Energy-efficient designs can help minimize electricity use while ensuring optimal pelletizing performance. For precise power requirements, it's best to consult the manufacturer specifications for each machine model.
Yes, many husk pellet machines are versatile enough to process other raw materials, such as straw, sawdust, wood shavings, and other biomass materials. This flexibility is due to the machine's adjustable settings and robust design, allowing it to handle various textures and densities. However, it’s essential to confirm specific material compatibility, as some machines may require slight modifications or adjustments for optimal performance with different raw materials.
Yes, operator training is essential for husk pellet machines. Proper training ensures that operators understand machine setup, operation, and maintenance to optimize production efficiency and prevent issues like clogging or uneven pellet quality. Training also covers safety protocols, which are crucial for handling high-temperature and high-pressure equipment. Well-trained operators can maximize machine performance, extend equipment lifespan, and minimize downtime, ultimately improving production quality and efficiency.
The average lifespan of a husk pellet machine is typically 10-15 years or more with proper maintenance. Regular care, such as cleaning, lubrication, and inspection of key components like dies and rollers, is essential to ensure durability and long-term performance. Proper usage, including adherence to recommended operating conditions, can also extend the machine’s life and enhance efficiency in husk pellet production.
