Aquatic Feed Pellet Making Machine
- Brand : RICHI
- Capacity : 5-7T/H
- Model : SZLH350
- Main Power : 55KW
-
Guiding Price :
FOB 7000-100000 USD
Brief Introduction
The material passing through the modulator enters the granulation chamber and rapidly extruded through the ring die and the press roller to form cylindrical pellets.
Get QuoteHigh efficiency, Stable and classical gear driving，non-slipping，can really ensure the production output. Low noise，optimized ring die，maximum output. Hygiene and safety. CE certified standard design and available stainless conditioner for feed，human and machine safety. Flexible production. Wide product rangeΦ1.5mm-Φ12mm pellets，conditioner with molasses and steam adding function. User-friendly operation. Hydraulic system for ring die change and roller adjustment（optional），quick ad precise operation；auto-lubrication system（optional）and die & roller lifting device，save labor；on-site touch screen control.
| Model | Capacity(TPH) | Main Motor Power(kw) | Feeder Motor Power(kw) | Conditioner Power(kw) | Dia.of Ring Die(mm) | Final Pellet(mm) |
| SZLH350 | 5-7 | 55 | 1.5 | 3 | 350 | 2~12 |
Aquatic Feed Pellet Making Machine
| Model | Capacity(TPH) | Main Motor Power(kw) | Feeder Motor Power(kw) | Conditioner Power(kw) | Dia.of Ring Die(mm) | Final Pellet(mm) |
| SZLH250 | 1-2 | 22 | 0.75 | 1.5 | 250 | 2~12 |
| SZLH320 | 3-4 | 37 | 1.5 | 2.2 | 320 | 2~12 |
| SZLH350 | 5-7 | 55 | 1.5 | 3 | 350 | 2~12 |
| SZLH420 | 8-12 | 110 | 1.5 | 7.5 | 420 | 2~12 |
| SZLH508 | 10-18 | 160 | 2.2 | 11 | 508 | 2~12 |
| SZLH558 | 15-25 | 180/200 | 2.2 | 11 | 558 | 2~12 |
| SZLH558D | 14-22 | 160/180/200 | 1.5 | 7.5 | 558 | 2~18 |
| SZLH678 | 20-30 | 220/250 | 2.2 | 11 | 678 | 2~12 |
| SZLH678D | 15-25 | 200/220/250 | 2.2 | 11 | 673 | 2~18 |
| SZLH768 | 25-40 | 280/315 | 2.2 | 11 | 768 | 2~12 |
| SLZH858 | 25-42 | 280/315 | 2.2 | 15 | 858 | 2~18 |
Application of Aquatic Feed Pellet Making Machine
It is based on crushed materials such as corn, soybean meal, and wheat, and widely used in grain and feed processing plants, aquatic farms, livestock farms, poultry farms, or large, medium and small feed processing plants.
Get Quote
Accessories
RICHI uses high-quality steel and has been processed through multiple processes to provide customers with high-quality ring dies and press rollers, and promises to use Siemens motors and SKF bearings.
Get Quote
-
SIEMENS
Motor
-
SKF
Bearing
-
Extruder
Discharging die
-
Extruder
Single-thread
Equipment In RICHI Workshop
- Cutter Adjustment Arm
- Pelletizing Chamber
- Aquatic Feed Pellet Machine
- Aquafeed Pellet Making Machine
Application
Our products are usually used in conjunction with other equipment in the production line and have a wide range of applications. The following are common pellet production lines for reference only. If you have different requirements, please contact us for customization.
