Automatic Bagging System

Automatic Bagging System
Brand : RICHI
Capacity : 6-8 BAGS/MIN
Model : DCS-B50/D
Main Power : 3KW

Guiding Price :
FOB 6000-20000 USD

Get Quote

Brief Introduction

Consists of a finished storage bin and weighing system for packaging finished feed pellets.

Get Quote

Unique Anti-vibration design to make sure the accurate measurement. strong anti-interference ability. It could work smoothly and perfectly in unstable and complex circumstance. The control and adjustment unit was set on the convenient position. user friendly. Belt feeding scale is suitable for powder and granular raw material; screw feeding scale is only suitable for powder material packing.

ModelApplicationFeeding MethodSpeedPowderPrecisionTemperature RangeAir Source
DCS-B50/DPellet/PowderBelt6-8bags/min3kwstatic±0.1% dynamic±0.2%-10~40℃0.4-0.6MPa 1.5m3/h

Automatic Bagging System

ModelDCS-C50/DDCS-A50/DDCS-B50/DDCS-B50/SDCS-A50/Y
ApplicationPelletPowderPellet/PowderPellet/PowderPremix
Feeding MethodGravityScrewBeltBeltScrew
Speed6-8bags/min6-8bags/min6-8bags/min10-12bags/min6-8bags/min
Powder1.1kw3kw3kw5kw3kw
Precisionstatic±0.1% dynamic±0.2%static±0.1% dynamic±0.2%static±0.1% dynamic±0.2%static±0.1% dynamic±0.2%static±0.1% dynamic±0.2%
Temperature Range-10~40℃-10~40℃-10~40℃-10~40℃-10~40℃
Air Source0.4-0.6MPa 1.5m3/h0.4-0.6MPa 1.5m3/h0.4-0.6MPa 1.5m3/h0.4-0.6MPa 1.5m3/h0.4-0.6MPa 1.5m3/h

Application of Automatic Bagging System

It is mainly used in feed production lines. As the last step of the equipment, the finished product is packaged for storage and transportation.

Get Quote

Accessories

RICHI manufactures high-spec accessories using high-quality steel to improve equipment quality and reduce customer maintenance costs.
